ACS 600

The Industry's Most Versatile Welder

The ACS-600 uses hot air or hot wedge to weld a wide range of seam configurations. This machine is also capable of welding straight, curved and radii seams.

Made in USA

Features

  • Controlled with an American made PLC / HMI combo (25 recipes)
  • High torque precision driven weld rollers
  • 3 different lower arm options. Straight, Angled or Swing Arm
  • The latest hot air / hot wedge technology
  • CNC machined components offer a more smooth and repeatable operation
  • Stainless steel prevents rust and wear
  • Can be custom built to your application

Capable of Welding

Fin Seal Fin Seal
Hem Hem
Hem with Pocket Hem with Pocket
Hem with Rope Hem with Rope
Keder Keder
Overlap Overlap
Web Reinforce Web Reinforce
+ More Welds + More

Requirements & Capabilities

  • Power Requirements: 208-230 Volts - Single Phase or Three Phase
  • Air Requirements: 80 psi, 4 CFM air pressure required
  • Electric Codes: NFPA 70, 79 NEC and CSA Guidelines
  • Max Temp Hot Air: 1382° F (750° C)
  • Max Temp Hot Wedge: 932° F (500° C)
  • Seam Width: 1/2" to 2" (12.7mm to 50.8mm)
  • Welding Cycle: Up to 110ft/min (33.5 m/min)

Size & Specs

  • Throat Width: 36" standard (92cm)
  • Width: 24" (61cm)
  • Length: 70" (178cm)
  • Height: 62" (157cm)

Weldable Materials

  • Vinyl (PVC) laminated fabrics
  • Vinyl-coated fabrics
  • Vinyl films
  • Polyurethane films
  • Polyethylene (PE)
  • Non-woven polyester
  • Polypropylene-coated fabrics
  • Woven polypropylene
  • Non-woven polypropylene
  • Thermoplastic rubber fabrics
  • Acrylics for awning and marine covers
  • Fusing tape
  • Weldable webbings
  • Any thermoplastic material / fabric

If your material and/or fabric is not listed, please contact ACS Inc. for a product test.
